RP03 Valvcheq/Tyco RPZ Expoxy coated 100mm Table D

0.00
0% Off

RP03 Valvcheq/Tyco RPZ Expoxy coated 100mm Table D

2

RP03 Valvcheq/Tyco RPZ Expoxy coated 100mm Table D flanged Reduced Pressure Zone Preventer.

This product is no longer available.


Product Features -  All pricing exclusive of GST

  • Size range: DN 65 - 150
  • Temperature rating: 1 ºC to 60 ºC
  • Working pressure: PN16
  • End connections: Flanged AS 4087
  • Compact simple design.
  • In-line and on-site serviceable.
  • No special tools required for servicing.
  • Lifting lugs to assist with installation.
  • Designed and manufactured in accordance
    with AS/NZS 2845.1
  • FBE coated to AS/NZS 4158.
  • Straight through flow path for maximum
    flow co-efficient.
  • Top entry allows parts to be accessed easily.
  • Stainless steel internals for superior
    corrosion resistance.
  • Fully restrained check valve assemblies
    for unrivalled safety.
  • Ductile Iron body for high strength and impact
    resistance.
  • Every valve is bench tested and tracked
    with unique serial number.
  • All internal components are repairable
    or replaceable.
  • All internal and external bolting is fully stainless steel.
  • Conforms to testing requirements
    of AS/NZS 2845.3.
  • Anti-tamper test taps.
  • Design conforms to all major
    international standards.
  • Recommended for horizontal installation only.
